180 / 230
Balustrade Systems
180
BALUSTRADE SYSTEM
www.fypon.comNOTE: For use in applications when installed no more than 30" above ground.
Part Number
Balustrade
System
Radius
A
B
C
BTRR5X60
5"
60"
3
1
/
4
"
3
1
/
8
"
4
5
/
8
"
BBRR5X60
5"
60"
4
1
/
2
"
3
1
/
8
"
3
3
/
4
"
A
C
B
A
C
B
Top
Bottom
Radius Rails
Part Number
Balustrade System Installation Notes
RSB4X3X6
u
5
Rail Support Block
5"
Install under the bottom rail at a span of
48" or less. Dimensions: 4" x 3" x 6
3
/
4
"
(may be trimmed for height)
RSB4X4X6
Rail Support Block
5", 7", 12"
Install under the bottom rail at a span of
48" or less. Dimensions: 4" x 4" x 7
1
/
4
"
(may be trimmed for height)
BRK5
Rail Installation Kit
5"
Connects both ends of one 5" top or
bottom rail to support structure.
Order two kits per section.
Kit Contents:
(2) Angle Brackets & Mounting Hardware
BRK6-7
Rail Installation Kit
7"
Connects both ends of one 7" top or
bottom rail to support structure.
Order two kits per section.
Kit Contents:
(2) Angle Brackets & Mounting Hardware
BRK12
Rail Installation Kit
12"
Connects both ends of one 12" top or
bottom rail to 12" newel post or other
support. Order two kits per section.
Kit Contents:
(4) Angle Brackets & Mounting Hardware
BRK12ANGLBKT
Rail Installation Kit
12"
Connects both ends of one 12" top
or bottom rail to 13" newel post only.
Order two kits per section.
Kit Contents:
(2) Angle Brackets & Mounting Hardware
Installation Aids
NEW
A
B
C
u
Available to order April 2015
5
Should be used with BBRS6X96, BBRC6X96, BTRS6X96, BTRC6X96.
