Window & Door Tri
m
POLYURETHANE CATALOG
1.800.446.3040 9
How to Order
Window Trim
To order window trim, first measure the window unit
to be trimmed. Next choose the desired products and
accessories to complete the look.
Door Trim & Entrance Systems
When ordering door trim, first measure the door unit to
be trimmed. The unit can be measured with or without
brick mould; however, the brick mould is essential when
using a storm door. Next choose the desired pilaster style
and size. Finally, choose a pediment or crosshead that is
wide enough to span the opening plus the brick mould
and pilasters (see example). Add desired accessories to
complete the look.
Window & Door Trim
Accessories
Keystones, dentil trim, trim strip and bottom trim
accessories are available attached to standard
products as fabricated products. Keystones can also
be ordered as unattached accessories by listing the
line item on your order.
Fabricated & Custom Products
Throughout this section, you will see fabricated
products with attached accessories that have specific
part numbers. To order a fabricated product shown in
this catalog, place your order using the part number
shown. Additional fabricated options may be available,
including additional sizes and routing options. To request
a fabricated product not shown in this catalog – or to
request a unique custom product design – please fill out
our Quote Request Form, which can be obtained at
, or contact
the Fypon Custom Product Sales Department
at 855.397.6647 or the Fypon Customer Service
Department at 800.446.3040.
How to Use This Section
The products in this section of the catalog are
organized by size, from smallest to largest. Where
applicable, part numbers are shown for fabricated
products with attached accessories, and matching
unattached accessories are referenced or shown
with the product.
Remember to Order Adhesive
A urethane-based adhesive must be used on all
joint surfaces. See page 200 to order Loctite® PL
Premium® Adhesive.*
Window & Door Trim Applications
Door Trim Terminology
Crosshead
Sunburst Pediment
Fluted Pilaster
Fluted Mull Pilaster
Plinth Block
Window Trim Terminology
Half-Round
Spoked Pediment
Arch Trim
End Cap
Moulding
Window Panel
Note: A keystone cannot be used
when combining a crosshead
with a pediment.
Keystone
Without Accessories With Accessories
7" Pilaster
Combination Pediment Width
2" Brick Mould
Flat Recessed
Keystone Options
with Bottom Trim
Window Crossheads with Attached Accessories
with Dentil Trim
MLD303 used on 6” Crosshead
MLD304 used on all other Crossheads
with Trim Strip
MLD602
with Keystone
* Loctite® PL Premium® is owned by Henkel Corporation.
Always consult the local building code authority to determine suitability of products to meet
specific project requirements.
Fypon reserves the right to hollow out the back of any product without notice. This space is
not intended to be used for blocking purposes. Some products may be made as assemblies.
Images are representative of style, actual product will vary by size.
