13 / 80
Rough Sawn Cedar Shutters
ROUGH SAWN CEDAR SHUTTERS
1.800.446.3040
13
n
We have greatly expanded our line to include multiple new styles, a new woodgrain, and a new size range
that includes widths of 12", 14", 18", and 24", and height from 24" to 120", available in 1" increments.
n
We have also added an accessory line of hinges and clavos that create a distinct look for your shutters.
n
The new line will be available in both board and batten and plank styles. Fypon now provides you with
numerous options, just what you would expect from the style leader.
Fypon is excited to introduce its
new line of woodgrain shutters!
SH3PC18X60RS[Profile]
SH
= Shutter
[Height]
(1" increments)
24
= 24" [Minimum]
120
= 120" [Maximum]
[Configuration]
2PC
= 2 Board, 2 Batten
3PC
= 3 Board, 2 Batten
4PC
= 4 Board, 2 Batten
2P3BC
= 2 Board, 3 Batten
3P3BC
= 3 Board, 3 Batten
4P3BC
= 4 Board, 3 Batten
2PZC
= 2 Board, Z Batten
3PZC
= 3 Board, Z Batten
4PZC
= 4 Board, Z Batten
2PEBC
= 2 Board, End Batten
3PEBC
= 3 Board, End Batten
4PEBC
= 4 Board, End Batten
[Width]
12
= 12"
14
= 14"
18
= 18"
24
= 24"
[Texture]
RS
= Rough Sawn Stain or Paint
BOARD & BATTEN LOGIC
SH3PO18X60RS[Profile]
SH
= Shutter
[Height]
(1" increments)
24
= 24" [Minimum]
120
= 120" [Maximum]
[Configuration]
2PO
= 2 Plank, 2 Batten
3PO
= 3 Plank, 2 Batten
4PO
= 4 Plank, 2 Batten
2P3B
= 2 Plank, 3 Batten
3P3B
= 3 Plank, 3 Batten
4P3B
= 4 Plank, 3 Batten
2PZ
= 2 Plank, Z Batten
3PZ
= 3 Plank, Z Batten
4PZ
= 4 Plank, Z Batten
2PD
= 2 Plank, Diamond
3PD
= 2 Plank, Diamond
4PD
= 2 Plank, Diamond
[Width]
12
= 12"
14
= 14"
18
= 18"
20
= 20"
24
= 24"
[Texture]
RS
= Rough Sawn Stain or Paint
PLANK LOGIC
SH3PHLR18X60RS
[Profile]
SH
= Shutter
[Height]
(1" increments)
24
= 24" [Minimum]
120
= 120" [Maximum]
[Configuration]
2PHLR
= 2 Board Quarter
3PHLR
= 3 Board Quarter
4PHLR
= 4 Board Quarter
[Width]
12
= 12"
14
= 14"
18
= 18"
24
= 24"
[Texture]
RS
= Rough Sawn Stain or Paint
QUARTER ROUND LOGIC
EW
Note:
Minimum height for Quarter Round
Shutters is double the width of the shutter.
Example:
SH3PHLR18x36RS – 18" = width
of shutter and 36”= height (twice the width)
BOARD & BATTEN
– JOINED BOARD AND BATTEN STYLES
2, 3,
OR
4
BATTEN
Batten styles
with joined
boards
END
BATTEN
Battens are placed
at the very end of
the boards
Z BATTEN
The horizontal
battens, or cross
Z, one placed
on the front of
the shutter
QUARTER
ROUND
Shutters that
mirror unique
arch top windows
ELLIPTICAL
A shutter top that
mirrors the shape
of a unique
elliptical window
DIAMOND
Decorative diamond
shape is centered
between the panels
PLANK
– SPACED BOARDS CREATE VISIBILITY OF SIDING BETWEEN SHUTTER BOARDS
2 & 3
PLANK
Batten styles
with spaced
boards
Z BATTEN
The horizontal
battens, or cross
Z, one placed
on the front of
the shutter
ELLIPTICAL
A shutter top that
mirrors the shape
of a unique
elliptical window
