Decorative Millwork
148
DECORATIVE MILLWORK
www.fypon.comTimber Trellis System
Stainable
Trellis Kit Part Number & Contents
Overall Width (Installed)
Overall Height (Installed)
Projection (Installed)
TRLS18987
Fits 16'-18' Garage Doors
(2)
BKT32X31X5S,
Outlooker
(4)
BMD4X8X144S,
12' Beam
(18)
FLTBA36X3X3S,
Rafter Tail
(1)
TRLS18989,
Hardware Kit
21' 9"
Over 16' Door
23' 9"
Over 18' Door
41
7
/
8
"
36"
TRLS18988
Fits 8'-9' Garage Doors
(2)
BKT32X31X5S,
Outlooker
(2)
BMD4X8X48S,
4' Beam
(2)
BMD4X8X144S,
12' Beam
(10)
FLTBA36X3X3S,
Rafter Tail
(1)
TRLS18994,
Hardware Kit
13' 9"
Over 8' Door
14' 9"
Over 9' Door
41
7
/
8
"
36"
Individual Trellis Components
Part Number
Projection
Height
Overall Width
BKT32X31X5S
Outlooker
32
1
/
2
"
30
5
/
8
"
5
1
/
4
"
BMD4X8X48S^
Beam
4
1
/
4
"
7
3
/
4
"
48"
BMD4X8X144S^
Beam
4
1
/
4
"
7
3
/
4
"
144"
FLTBA36X3X3S^
Lattice
36"
3
1
/
2
"
2
3
/
4
"
TRLS18989
Hardware Kit for
TRLS18987
Kit Contains:
(3) Angle Bracket
(3) U Bracket
(1) Screw Pack
(1) Installation Guide
—
—
TRLS18994
Hardware Kit for
TRLS18988
Kit Contains:
(2) Angle Bracket
(2) U Bracket
(1) Screw Pack
(1) Installation Guide
—
—
NOTE: See page 127 for smooth trellis.
^ This product is not finished on all sides.
NOTE: For installation instructions, please visit
www.fypon.com.
Scrolled profile on one end
only
Angled on one end
only
