Louvers & Gable Vents
POLYURETHANE CATALOG
1.800.446.3040 153 P LY ET A E CATAL
1.8 0. 46.3040
How to Order
Louvers
The first step when ordering a louver is to find the
proper size for your specific application by measuring
the width and height. Then find the louver you
need to order by locating your desired style with
corresponding measurements on the following pages.
Functional Louvers**
If you are ordering a functional louver, you should
order a louver that is approximately 2” larger than your
rough opening on all sides of the louver. This will allow
you to attach the louver to the substrate through the
brick mould edge.
Louver Accessories
Keystones and trim are available pre-attached to
standard products as fabricated items. Keystones and
trim can also be ordered as unattached accessories
by listing the matching part number as a separate line
item on your order.
Fabricated & Custom Products
Some products shown in this section are available
with fabricated options. This means one or more
standard parts can be altered to create additional
sizes, attach accessories or route a channel to accept
siding. To request a fabricated product – or to request
a unique custom product design – please fill out our
Quote Request Form, which can be obtained at www.
, or contact the Fypon
Custom Product Sales Department at 855.397.6647
or the Fypon Customer Service Department at
800.446.3040.
The products in this section of the catalog are
organized by louver style followed by matching
trim. Where applicable, matching keystones are
referenced for each louver and trim piece.
How to Use This Section
Remember to Order Adhesive
A urethane-based adhesive must be
used on all joint surfaces. See page 200
to order Loctite® PL Premium® Adhesive.*
4F Trim
(Actual Size 3 ½")
6F Trim
(Actual Size 5 ½")
Keystone for 4F
and 6F Trim
Keystone for Louver
with Brick Mould
Plus 4F Trim
20"
14"
Order
LV18X24
14" x 20"
Rough
Opening
Keystone
(For Brick Mould
Profile on Louver)
Keystone
(For Trim Profile)
Louver Keystone Applications
Keystone for
Louver
* Loctite® PL Premium® is owned by Henkel Corporation.
** Always consult the local building code authority to determine suitability of products to
meet specific project requirements.
Fypon reserves the right to hollow out the back of any product without notice. This space is
not intended to be used for blocking purposes. Some products may be made as assemblies.
Images are representative of style, actual product will vary by size.
